The company says HSMXpress is a “truly integrated CAM system for 2D and 2-1/2 D CNC programming” that can be used to turn designs into real machined parts. Graves called the announcement the most important day in HSMWorks’ history. DE’s Publisher, Tom Conlon, was at the show and interviewed Graves about the new product. A 32-bit version is also available.Īnthony Graves, marketing director for HSMWorks, made the HSMXpress announcement today at the Performance Racing Industry trade show in Orlando. Select Inner, Outer, or Both depending on Track Type.HSMWorks has released HSMXpress, a free CAM solution that the company says allows all licensed users of SolidWorks 2009 or newer to create high-quality toolpaths using the latest in 64-bit and multi-core technology.

Angular Increment - Maximum angle between two consecutive curve points.Chordal Tolerance - Maximum distance from the chord between two consecutive curve points and the curve itself.You can control the resolution or tolerance between the points on these entities.

Cam tracks are comprised of arcs, curves, and lines where the points on the curve are calculated based on your selections on the Motion tab. Depth cannot be greater than Blank Thickness.

Blind - Type the depth of the cam track into the cam surface.

Specifies the diameter of the hole that goes through the hub. Specifies the radius of the fillet between the hub and the cam surface and the value for the chamfer at the top face of the hub. The far side is opposite the side where the cam is cut for a cam with a blind track surface. Specifies the diameter of the hole and the distance from the cam surface to the top of the hub on the far side of the cam. The near side is where the cam is cut for a cam with a blind track surface. Specifies the diameter of the hole and the distance from the cam surface to the top of the hub on the near side of the cam. Specifies the outside diameter of the circular cam and the thickness of the cam plate. (Read-only.) Displays the cam type and number of motion definitions.
